Tc4 grade 5 titanium alloy sheet
1. form: sheet, coil, strip, bar, tube, wire
2. Supply capacity: more than 5000T
3. From the quantitative: more than 1T
4. Delivery time: 3-45 days
5. Port Delivery: Shanghai
Get A Free Quote
Description

Tc4 titanium alloy sheet metal material ti6al4v grade 5 titanium price per kg

Product description:

product nameSpecifications
Titanium Rod & Bar & Ingots 3mm~1020mm,the maximum weight is up to 12t
Titanium Slab(80~400)mm×(~1500)mm×(~2600)mm
Titanium ForgingsWeight per piece≤2000kg
Titanium Hot-rolled plates(4~100)mm×(800~2600)mm×(2000~12000)mm
Titanium Cold-rolled Sheet(0.01~4.0)mm×(800~1560)mm×( ~6000) mm
Titanium Foil / Strips(0.01~2.0)mm×(800~1560)mm×L
Titanium Tubes / Pipes(3~114)mm×( 0.2~5)mm × (~15000)mm
StandardsGB,GJB,ASTM,AMS,BS,DIN,DMS,JIS,
Titanium GradeGR1,GR2,GR3,GR5,GR7,GR12
BT1-00,BT1-0,BT1-2
TA0,TA2,TA3,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4


Tc4 grade 5 titanium alloy sheet

Tc4 grade 5 titanium alloy sheet

Tc4 grade 5 titanium alloy sheet



 1.Chemical requirements of titanium plate


NCHFeOAlVPaMoNiTi
Gr 10.030.080.0150.20.18/////bal
Gr 20.030.080.0150.30.25/////bal
Gr 30.050.080.0150.30.35/////bal
Gr 40.050.080.0150.50.4/////
Gr 50.050.080.0150.40.25.5~6.753.5~4.5///bal
Gr 70.030.080.0150.30.25//0.12~0.25//bal
Gr 90.030.080.0150.250.152.5~3.52.0~3.0///bal
Gr120.030.080.0150.30.25///0.2~0.40.6~0.9bal



2.Tensile requirements of titanium plate

gradeTensil strength(min)Yeild strength(min)Elongation(%)
ksiMPaksiMPa
1352402013824
2503454027520
3654505538018
4805507048315
513089512082810
7503454027520
9906207043815
12704385034518



3. Technological process of titanium plate



Tc4 grade 5 titanium alloy sheet



Shipping of titanium plate

TNT, EMS, UPS, FED, DHL, Air transport, Sea Transport, Railway Transport are available. Depends on your demands, we will try our best to choose the most suitable way for you. After we send the product, we will send the track number to you with Email, and also we will track this order until you can received successfully.
