2.0mm 18g/cc tungsten super shot
Material: Stainless steel
Shape: round
Series: 4 inch
Features: anti-odour
Product specifications: 100X100mm
MOQ: 300PCS
The field of application: Bathroom,Kitchen
Get A Free Quote
Description

2.0mm 18g/cc tungsten super shot

Tungsten shot can be used in many areas,the main advantages of tungsten shot are that it's very dense,

and very hard. The density allows it fly long distances without slowing down, while the hardness

allows it to keep their shape while being accelerated by the powder charge, which increases the muzzle velocity.

Product NameGram 0.075g 2.0mm tungsten shot/sphere for bearings
Material97W-Ni-Fe 95W-Ni-Fe 93W-Ni-Fe
Colorsilver metallic luster
Packagemetal bucket or carton box
Diamieter2.0mm, 2.2mm, 2.25mm,2.5mm,2.75mm etc
Advantagehigh density, high melting point, small volume
Applicationball bearing, seat valve



Application:



1. Tungsten alloy sphere is very dense and small in volume, which means it can be used in fields requiring small but heavy parts.



2. Counterweights in golf clubs, fishing weightscounterweights for military defense,equipment, counterweights, prefabricated fragments, oil logging.



3. Also some fields in precision industry, such as mobile phone vibrator, clock cube, self-winding watches, anti-vibration toll holders, flywheel weihts, etc.



Size ( mm )Weight ( g )Size Tolerance ( mm )Weight Tolerance ( g )
1.50.0321.49-1.150.030-0.035
2.00.0751.98-2.020.070-0.078
2.50.1472.48-2.520.142-0.150
2.80.2072.78-2.820.20-0.21
3.00.2542.97-3.030.25-0.26
3.50.4043.47-3.530.39-0.41
4.00.6033.96-4.040.58-0.62
4.50.8584.46-4.540.82-0.88
5.01.1764.95-5.051.14-1.2
5.51.5675.45-5.551.53-1.60
5.61.6555.55-5.651.60-1.67
6.02.0355.94-6.061.98-2.07
6.52.5876.44-6.562.55-2.59
7.03.2316.93-7.071.98-2.07
7.53.9477.43-7.573.90-3.98
8.04.8237.92-8.084.78-4.9
10.09.4209.92-10.089.35-8.50
Density: 18g/ccDensity tolerance: 17.75 - 18.15 g/cc







Specification
MaterialDensity ( g/cm3 )Tensile Strength ( Mpa)Elongation ( % )HRC
90W-Ni-Fe16.9-17700-100020-3324-32
93W-Ni-Fe17.5-17.6100-100015-2526-30
95W-Ni-Fe18-18.1700-9008-1525-35
97W-Ni-Fe18.4-18.5600-8008-1430-35




2.0mm 18g/cc tungsten super shot2.0mm 18g/cc tungsten super shot


2.0mm 18g/cc tungsten super shot



Products Show








Package type : a, Steel drum packing

1).250 kg per steel drum

2) 4 drums on one pallet


3) Drum with pallet size: 75*75*65cm


b, Carton package

1) 25 kg per carton , 36 cartons on one pallet

2) Carton size: 30*20*15

Delivery

By air

By shipping

By railway
