form: | Plates/Sheets/Coils/Strips |
surface: | 2B / 2D / BA |
thickness: | 0.05MM to 3MM |
hardness: | 1/4 Hard, 1/2 Hard, 3/4 Hard, Full Hard, Spring Hard, Annealed, Pickled Soft |
Chemical composition:
Alloy | % | Ni | Cu | Al | Fe | Ti | Co | Mn | S | C | Si | P | Cr | Mo | B |
N09901 | Min. | 40.0 |
|
| Balance | 2.35 |
|
|
|
|
|
| 11.0 | 5.0 | 0.01 |
Max. | 45.0 | 0.50 | 0.35 | 3.10 | 1.0 | 1.0 | 0.03 | 0.10 | 0.60 | 0.03 | 14.0 | 7.0 | 0.02 |
Physical properties:
Density | 8.14 g/cm3 |
Melting point | 1280-1345°C |
Minimum mechanical properties in the room temperature:
Status | Tensile strength RmN/mm2 | Yield strength RP0.2N/mm2 | Elongation A5% |
N09901 | 1034 | 689 | 12 |
