1. AISI H13, DIN 1.2344, JIS SKD61, 4Cr5MoSiV1 Hot work tool steel
2. Hot rolled or Forged, condition annealing, black surface
3. Hardness: ≤ 255HBS;
4. Hot rolled technology: EAF+LF+VD
5. Ultrasonic test standard: SPE1921-GR3, CLASS D/D or E/E
| Standard | Grade | Chemical composition (%) |
|
| C | Si | Mn | Cr | Mo | V | Ni | W | Cu | Ti |
| GB | 4Cr5MoSiV1 | 0.32-0.42 | 0.80-1.20 | 0.20-0.50 | 4.75-5.50 | 1.10-1.75 | 0.80-1.20 | -- | -- | -- | -- |
| AISI | H13 | 0.30-0.40 | 0.80-1.20 | 0.20-0.40 | 4.75-5.50 | 1.25-1.75 | 0.80-1.20 | -- | -- | -- | -- |
| JIS | SKD61 | 0.35-0.42 | 0.80-1.20 | 0.25-0.50 | 4.80-5.50 | 1.00-1.50 | 0.80-1.15 | -- | -- | -- | -- |
| DIN | 1.2344 | 0.37-0.42 | 0.90-1.20 | 0.30-0.50 | 4.80-5.50 | 1.20-1.50 | 0.90-1.10 | -- | -- |
|
|
| Size of SKD61/1.2344 Hot Work Mould Steel |
| Round bar | Diameter(mm) | Length (mm) |
|
| Max:800 | Max: 9000 |
|
| Plate | Thickness(mm) | Width (mm) | Length (mm) |
| Max:800 | Max:1000 | Max:6500 |
Applications:
1. Diecasting mould(mold, fixed block, upper die, jet nozzle, nitride thimble ).
2. Extrusion die(mold, supporting member, choke blocks).
3. Hot press die. (aluminum, magnesium, copper alloy)
4. Parts, such as cold cutting, overlap, hot shears, wearable parts.
5. Important parts for aviation industry.
| Grade | No. | C | Si | Mn | P,max | S,max | Cr | Mo | Ni |
| AISI 4340/40NiCrMo7 | 1.6562 | 0.37-0.44 | 0.17-0.37 | 0.5-0.8 | 0.035 | 0.035 | 0.6-0.9 | 0.15-0.25 | 1.25-1.65 |
| Grade | No. | C | Si | Mn | P,max | S,max | Cr | Cu,max | Ni,max |
| AISI 1045/45# | 1.0503 | 0.42-0.5 | 0.17-0.37 | 0.5-0.8 | 0.035 | 0.035 | 0.25 | 0.25 | 0.25 |
| Category | Grades | Sizes | Standard |
| Carbon structure steel | Q195, Q215, Q235, Q275 | 16mm-680mm | GB/T700-2006 |
| Low alloy high strength structure steel | Q295, Q345, Q390, Q420, Q460 | 16mm-680mm | GB/T1591-2008 |
|
| Prime Carbon structure steel | 10#, 20#, 35#, 45#, 60#, 20Mn, 65Mn, | 16mm-680mm | GB/T699-1999 |
| B2,B3, JM20, SH45,S45C, C45 |
| Alloy structure steel | 30Mn2, 40Mn2, 27SiMn, 42Crmo,20Cr, | 16mm-680mm | GB/T3077-1999 |
| 40Cr, 20CrMo, 35CrMo,20CrMnTi, |
| 30CrMnTi,20MnVB, 20MnTiB, 20CrNiMo, |
| Q345B, 35MnBM, 40MnB,36Mn2V, 45MnV, |
| Spring Steel | 65Mn, 60Si2Mn, 50CrVA | 16mm-680mm | GB/T1222-84 |
| Bearing Steel | GCr15, GCr15GD,55SiMoV | 16mm-680mm | GB/T18254-2002 |
| Structural steels subject to end-quench hardenability requirements | 20CrMnTi, 30CrMnTi, 20Cr, 40Cr, 30CrMo, | 16mm-680mm | GB/T5216-2004 |
| 42CrMoA, 27SiMn, 40Mn2H, 20CrNiMo, |
| 40Mn2, q345b, 35MnBM, 40MnB,45MnV. |
| Oil wells structural steel | 37Mn5, 36Mn2V | 16mm-680mm | Q/LYS248-2007 |
| Marine anchor chain steel | CM490, CM690, M30Mn2 | 16mm-680mm | YB/T66-1987 |
| GB/T18669-2002 |
finished product
Packaging:
of 95%wnife tungsten heavy alloy sheet plate
Packing Details : Plastic bags and kraft paper as inside, wooden case as outside.
Delivery Details : 2-15 workdays after order of tungsten carbide sheet, plate, foil, strip, cube, block and target.
FAQ:
1.How to get a quotation?
Grade? Thickness? Width? length? Quantity? Application?
2.Do you accept customed?
Yes, we can according to your drawings processing.
3.What is the shipping cost?
It mainly depends on weight, volume, packing size and destination port.
4.What's your delivery time?
In stock, 1-2 days, if not, according to your quantity.
